Sveltos: Introduction to Pull Mode

· 8 min read
Eleni Grosdouli
Eleni Grosdouli
DevOps Consulting Engineer at Cisco Solutions GmbH

Summary:

Sveltos v1.0.0 release introduced a way to manage Kubernetes clusters in restricted network, environments behind a firewall or edge locations. Follow along to understand how the Sveltos Pull Mode works and how it can be deployed.

Scenario​

When working with multi-cloud setups, there are scenarios where Kubernetes clusters reside in isolated network segments, behind firewalls, at edge locations with limited connectivity, or within air-gapped environments that require careful configuration and security controls. How can we manage these clusters and deploy add-ons and applications seamlessly while ensuring continuous drift-detection and reconciliation?

In today's post, we will install Sveltos in a Civo cluster, register an RKE2 cluster hosted in AWS behind a firewall using the Pull Mode and an AKS cluster in default mode, Push Mode. After the cluster registration, we will proceed with the Kyverno installation on both clusters for policy management, security and compliance, while installing Cilium Tetragon on the RKE2 cluster for security observability and runtime enforcement. Let's dive into the details!

Lab Setup​

+-------------------------------+---------------------+
|         Deployment             |       Version      |
+-------------------------------+---------------------+
|           Civo                 |   v1.31.6+k3s1     |
|           RKE2                 |     v1.32.5        |
|           AKS                  |     v0.24.1        |
|          Sveltos               |      v1.0.1        |
+-------------------------------+---------------------+

Diagram​

title image reading "Sveltos Pull Mode

Prerequisites​

  1. A Kubernetes management cluster
  2. sveltosctl installed
  3. Sufficient rights to access the management and the managed clusters
  4. (Optional) access to the AWS and AKS environment

How does Pull Mode work?​

Coming directly from the Sveltos official documentation.

  1. Management Cluster: It defines the desired state. We define our ClusterProfile/Profile resources in the management cluster, specifying which add-ons and configurations should be applied to which managed clusters by utilising the Kubernetes labels selection concept.
  2. Managed Cluster: Rather than the management cluster initiating all deployments, a component on the managed cluster initiates a connection to the management cluster.
  3. Configuration Fetching: The managed cluster pulls the relevant configuration, manifest, or Helm chart from the management cluster. The management cluster prepares the relevant configuration bundle for the managed clusters in Pull Mode.
  4. Apply: The managed cluster's local agent applies the pulled configurations to the cluster.

As the managed cluster sits in a restricted location, the configuration bundle is prepared by the management cluster. The managed cluster initiates a connection to the management cluster and gets the configuration bundle. Once the resources are provisioned, the configuration bundle is removed from the management cluster.

Sveltos Installation​

We will install Sveltos as a Helm chart in Mode 1. To explore more about the different installation methods, have a look here.

Helm Chart Installation​

Follow the commands below and install Sveltos on a Kubernetes management cluster.

$ export KUBECONFIG=</path/to/Civo/management-cluster/kubeconfig>

$ helm repo add projectsveltos https://projectsveltos.github.io/helm-charts
$ helm repo update

$ helm install projectsveltos projectsveltos/projectsveltos -n projectsveltos --create-namespace --version=1.0.1

Validation

$ kubectl get pods -n projectsveltos

$ kubectl get sveltoscluster -A
NAMESPACE   NAME         READY   VERSION        AGE
mgmt        mgmt         true    v1.31.6+k3s1   39m

Sveltos Managed Cluster Registration​

RKE2 on AWS - Pull Mode​

As mentioned, the RKE2 cluster is behind a firewall. Only specific resources can be reached by the cluster. Thus, we will register this cluster in Pull Mode. Pointing the KUBECONFIG to the management cluster, execute the registration command. For more information about the registration process, visit here.

$ export KUBECONFIG=</path/to/Civo/management-cluster/kubeconfig>

$ sveltosctl register cluster \
    --namespace=rke2\
    --cluster=cluster01 \
    --pullmode \
    --labels=env=test \
    > rke2_reg.yaml

Once the command is executed, Sveltos creates a manifest file that holds relevant resources about the cluster to be registered in Pull Mode. The secret contains the kubeconfig that is dynamically generated using the token associated with the service account located in the same file. Apart from that, Sveltos adds a new entry to the Sveltoscluster resource.

$ kubectl get sveltosclusters -A
NAMESPACE   NAME        READY   VERSION        AGE
mgmt        mgmt        true    v1.31.6+k3s1   50m
rke2        cluster01                          2s

We can see that cluster01 in the rke2 namespace is not READY yet, as it has no way to connect with the Sveltos management cluster. Let's go ahead and register the RKE2 cluster with Sveltos.

Ensure the KUBECONFIG points to the RKE2 cluster and apply the rke2_reg.yaml manifest created above.

$ export KUBECONFIG=</path/to/RKE2/managed-cluster/kubeconfig>

$ kubectl apply -f rke2_reg.yaml
namespace/projectsveltos created
serviceaccount/sveltos-applier-manager created
clusterrole.rbac.authorization.k8s.io/sveltos-applier-manager-role created
clusterrolebinding.rbac.authorization.k8s.io/sveltos-applier-manager-rolebinding created
service/sveltos-applier-metrics-service created
deployment.apps/sveltos-applier-manager created
secret/cluster01-sveltos-kubeconfig created

Validation​

Once the resources are available, heading back to the Sveltos management cluster, we can see that cluster01 is in a READY state.

$ export KUBECONFIG=</path/to/Civo/management-cluster/kubeconfig>

$ kubectl get sveltosclusters -A
NAMESPACE   NAME        READY   VERSION        AGE
mgmt        mgmt        true    v1.31.6+k3s1   51m
rke2        cluster01   true    v1.32.5        65s

This is great! We can now proceed with the AKS cluster and then start with the deployment of add-ons and applications to the cluster!

AKS - Push Mode​

Either using the sveltosctl or the programmatic approach, we will register the AKS cluster with Sveltos in Push Mode. To keep it concise, the sveltosctl is used.

$ export KUBECONFIG=</path/to/Civo/management-cluster/kubeconfig>

$ sveltosctl register cluster \
    --namespace=aks \
    --cluster=cluster02 \
    --kubeconfig=aks_kubeconfig.yaml \
    --labels=env=test

Validation​

$ export KUBECONFIG=</path/to/Civo/management-cluster/kubeconfig>

$ kubectl get sveltosclusters -A --show-labels
NAMESPACE   NAME        READY   VERSION        AGE      LABELS
aks         cluster02   true    v1.32.6        20s      env=test,projectsveltos.io/k8s-version=v1.32.6,sveltos-agent=present
mgmt        mgmt        true    v1.31.6+k3s1   52m      projectsveltos.io/k8s-version=v1.31.6+k3s1,sveltos-agent=present
rke2        cluster01   true    v1.32.5        125s     env=test

Sveltos ClusterProfiles​

During the registration process, we assigned the label env: test to both clusters. In this section, we will install Kyverno as a common Helm chart deployment and then Cilium Tetragon only in the RKE2 cluster.

Kyverno​

---
apiVersion: config.projectsveltos.io/v1beta1
kind: ClusterProfile
metadata:
  name: deploy-kyverno
spec:
  clusterSelector:
    matchLabels:
      env: test
  syncMode: Continuous
  helmCharts:
  - repositoryURL:    https://kyverno.github.io/kyverno/
    repositoryName:   kyverno
    chartName:        kyverno/kyverno
    chartVersion:     v3.5.1
    releaseName:      kyverno-latest
    releaseNamespace: kyverno
    helmChartAction:  Install
$ export KUBECONFIG=</path/to/Civo/management-cluster/kubeconfig>

$ kubectl apply -f clusterprofile_kyverno.yaml

What are the differences between Pull and Push mode when it comes to the Kyverno Helm chart deployment?

  • AKS Push Mode: In the default mode, Sveltos fetches the Kyverno Helm Chart to the management cluster and uses the Helm golang libraries to deploy it to the selected managed clusters.
  • RKE2 Pull Mode: In this mode, Sveltos fetches the required resources and builds a configuration bundle for the management cluster. The agent in the RKE2 cluster starts a watcher and immediately knows when a new configuration needs to be depoloyed or withdrawn. The managed cluster initiates a connection to the management cluster.

To check what the configuration bundle looks like in the management cluster, execute the command below.

$ kubectl get configurationbundle -A
NAMESPACE   NAME                          AGE
rke2        config-0gdr5cqfqeb2ch6vnd9i   10s
rke2        config-2mdu7uw2vleritlx74xx   10s
rke2        config-2n2spj29ntt13v13gnlq   10s
rke2        config-6967nmjsiivmoluf5et5   12s
rke2        config-6g4e21ujapn8fh0yxsqm   10s
...
note

In Pull Mode, once the resources are provisioned, they are deleted from the management cluster.

Cilium Tetragon​

Cilium Tetragon enables powerful realtime, eBPF-based Security Observability and Runtime Enforcement.

It is required only on the RKE2 cluster. For that reason, we will add a new label to the cluster01 named req: tetragon and create a new ClusterProfile.

$ kubectl label sveltosclusters cluster01 -n rke2 req=tetragon
---
apiVersion: config.projectsveltos.io/v1beta1
kind: ClusterProfile
metadata:
  name: tetragon-rke2-deploy
spec:
  clusterSelector:
    matchLabels:
      req: tetragon
  helmCharts:
  - chartName: cilium/tetragon
    chartVersion: 1.5.0
    helmChartAction: Install
    releaseName: tetragon
    releaseNamespace: kube-system
    repositoryName: cilium
    repositoryURL: https://helm.cilium.io/
$ export KUBECONFIG=</path/to/Civo/management-cluster/kubeconfig>

$ kubectl apply -f clusterprofile_tetragon.yaml

Because we target the RKE2 cluster, Cilium Tetragon will get deployed only on this cluster, following the approach described above. The AKS cluster will remain intact.

Validation​

$ kubectl get clusterprofile,clustersummary -A
NAME                                                     AGE
clusterprofile.config.projectsveltos.io/deploy-kyverno   39s
clusterprofile.config.projectsveltos.io/tetragon-rke2-deploy  10s

NAMESPACE   NAME                                                                       AGE
aks         clustersummary.config.projectsveltos.io/deploy-kyverno-sveltos-cluster02   39s
rke2        clustersummary.config.projectsveltos.io/deploy-kyverno-sveltos-cluster01   39s
rke2        clustersummary.config.projectsveltos.io/tetragon-rke2-deploy-cluster01     10s

Conclusion​

With Sveltos, you can easily manage different Kubernetes clusters, no matter where they are or how their networks are set up! 🎉
