Dual-Stack: Rancher RKE2 With Cilium on Proxmox

Introduction

Welcome to part 2 of the dual-stack series! In part 1, we covered how to enable IPv6 Prefix allocation using pfsense on Proxmox with Fritz!Box as a home router. The setup allows virtual machines in a dedicated interface to receive an IPv4 and an IPv6 address. If you have completed part 1, you can continue with the dual-stack RKE2 setup powered by Cilium.

Source

In later sections, we go through configuring the RKE2 clusters and performing different tests to ensure the dual-stack setup is functional. Ready to get started? Let’s dive in!

Lab Setup

+----------------------------+-------------------------+
|        Deployment           |         Version         |
+----------------------------+-------------------------+
|        Proxmox VE           |          8.2.4          |
|        pfSense              |          1.8.1          |
|        RKE2                 |      v1.29.12+rke2r1    |
|        Cilium               |          1.16.4         |
+----------------------------+-------------------------+

Prerequisites

• Virtual Machine with a dual-stack setup

Virtual Machines

Before we begin with the cluster setup, ensure the base image used for the virtual machines fits the RKE2 support matrix found here.

For today's demonstration, an SLES 15 SP5 image is used. The same setup should work for an Ubuntu 22.04 and an Ubuntu 24.04 image. This needs to be evaluated though! Let me know in the discussion section.

RKE2 Server Setup

For the server and the agent configuration, we follow the official documentation. However, it will be adjusted to support a dual-stack deployment. Now, it is the right moment to decide what the IPv6 Prefix for the cluster-cidr and the service-cidr are. 😊

Check IP Address Allocation

The network interface used by the virtual machine should already have an IPv4 and IPv6 address assigned via DHCP and DHCPv6 respectively. The virtual machine interface should look similar to the one below.

$ $ ip address
2: eth0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000
    link/ether bc:24:11:47:47:e1 brd ff:ff:ff:ff:ff:ff
    altname enp0s18
    altname ens18
    inet 10.10.20.126/24 brd 10.10.20.255 scope global eth0
       valid_lft forever preferred_lft forever
    inet6 2001:xxx:xxxx:xxxx::111f/128 scope global dynamic
       valid_lft 5045sec preferred_lft 2345sec
    inet6 fe80::be24:11ff:fe47:47e1/64 scope link
       valid_lft forever preferred_lft forever

RKE2 Server Configuration

$ mkdir -p /etc/rancher/rke2/

echo "
write-kubeconfig-mode: 0644
tls-san:
  - <YOUR NODE NAME>
token: <YOUR TOKEN>
cni: cilium
cluster-cidr: "10.42.0.0/16,2001:face:42::/56"
service-cidr: "10.43.0.0/16,2001:face:43::/112"
node-ip: "10.10.20.126,2001:xxxx:xxxx:xxxx::111f"
disable-kube-proxy: true
etcd-expose-metrics: false
" > /etc/rancher/rke2/config.yaml

The most important aspects of the configuration are the cluster-cidr and service-cidr. For the node-ip, we define the IPv4 and IPv6 addresses of the network interface seen previously. Apart from that, we disable the kube-proxy as it will be replaced by Cilium.

tip

For the second RKE2 cluster, ensure the cluster-cidr and service-cidr definitions are not overlapping as in part 3 we will introduce a Service Mesh between the two clusters.

Cilium Configuration

Going through the Cilium official documentation for IPv6 we need to enable the ipv6.enabled=true option during the Helm chart installation. If IPv6 BIG TCP is required, include the option enableIPv6BIGTCP=true.

$ mkdir -p  /var/lib/rancher/rke2/server/manifests

echo "
apiVersion: helm.cattle.io/v1
kind: HelmChartConfig
metadata:
  name: rke2-cilium
  namespace: kube-system
spec:
  valuesContent: |-
    image:
      tag: v1.16.4
    kubeProxyReplacement: true
    k8sServiceHost: <Sever FQDN or IP Address>
    k8sServicePort: 6443
    operator:
      replicas: 1
    ipv6:
      enabled: true
    hubble:
      enabled: true
      relay:
        enabled: true
      ui:
        enabled: true
" > /var/lib/rancher/rke2/server/manifests/rke2-cilium-config.yaml

note

By default, VXLAN tunnelling for routing is enabled. For more information about the available routing options, have a look here.

Install RKE2 Server

If a later version of RKE2 is available or required, check out the release page.

$ curl -sfL https://get.rke2.io |INSTALL_RKE2_VERSION=v1.29.12+rke2r1 INSTALL_RKE2_TYPE=server sh -

$ systemctl enable --now rke2-server.service # This might take a few seconds to ensure the service is in a healthy state
$ systemctl start rke2-server # Ensure the rke2-serer service is running
$ systemctl status rke2-server # Ensure the rke2-serer service is healthy

Kubeconfig

The kubeconfig is located under /etc/rancher/rke2/rke2.yaml. To interact with the cluster, use export KUBECONFIG=/etc/rancher/rke2/rke2.yaml and kubectl get nodes for validation.

RKE2 Agent Setup

To connect an RKE2 agent to the cluster, we need to ensure the virtual machines can talk to each other from a network point of view and then define the RKE2 configuration which includes the RKE2 Server URL and the token generated in a previous step. Then, we can continue with the installation of the RKE2 agent.

RKE2 Agent Configuration

$ mkdir -p /etc/rancher/rke2/

$ echo "
server: https://<Sever FQDN or IP Address>:9345
token: <YOUR TOKEN>
" > /etc/rancher/rke2/config.yaml

Install RKE2 Agent

$ curl -sfL https://get.rke2.io |INSTALL_RKE2_VERSION=v1.29.12+rke2r1 INSTALL_RKE2_TYPE=agent sh -

$ systemctl enable --now rke2-agent.service # This might take a few seconds to ensure the service is in a healthy state
$ systemctl start rke2-agent # Ensure the rke2-serer service is running
$ systemctl status rke2-agent # Ensure the rke2-serer service is healthy

Cluster Validation

Either from a jump host or the server (master) node, perform the validation and ensure the cluster is in a Ready state, contains two nodes in total and dual-stack networking is available.

$ kubectl get nodes
NAME       STATUS   ROLES                       AGE     VERSION
master03   Ready    control-plane,etcd,master   9m30s   v1.29.12+rke2r1
worker03   Ready    <none>                      112s    v1.29.12+rke2r1

$ kubectl describe nodes | grep -i 'Internal'
  InternalIP:  10.10.20.132
  InternalIP:  2001:xxx:xxxx:xxxx::1539
  InternalIP:  10.10.20.141
  InternalIP:  2001:xxx:xxxx:xxxx::1fb3

$ kubectl describe nodes | grep -i 'PodCIDRs'
PodCIDRs:                     10.42.0.0/24,2001:face:42::/64
PodCIDRs:                     10.42.1.0/24,2001:face:42:1::/64

The cluster nodes have an IPv4 and an IPv6 address assigned while the Pod CIDR matches the configuration details mentioned above.

Pod to Pod Communication IPv6

Let's create two pods, test01 and test02. The well-known network image netshoot is used and we will assign the pods to two different nodes. Use the nodeName specification.

• For more information about the netshoot image, have a look here.

$ kubectl get pod test01 -o jsonpath='{.status.podIPs[1].ip}'
2001:face:42::c36e

$ kubectl get pod test02 -o jsonpath='{.status.podIPs[1].ip}'
2001:face:42:1::41d5

Connectivity Test

$ kubectl exec -it test02 -- ping 2001:face:42::c36e
PING 2001:face:42::c36e (2001:face:42::c36e) 56 data bytes
64 bytes from 2001:face:42::c36e: icmp_seq=1 ttl=63 time=0.270 ms
64 bytes from 2001:face:42::c36e: icmp_seq=2 ttl=63 time=0.210 ms
64 bytes from 2001:face:42::c36e: icmp_seq=3 ttl=63 time=0.238 ms

$ kubectl exec -it test01 -- ping 2001:face:42:1::41d5
PING 2001:face:42:1::41d5 (2001:face:42:1::41d5) 56 data bytes
64 bytes from 2001:face:42:1::41d5: icmp_seq=1 ttl=63 time=0.371 ms
64 bytes from 2001:face:42:1::41d5: icmp_seq=2 ttl=63 time=0.233 ms
64 bytes from 2001:face:42:1::41d5: icmp_seq=3 ttl=63 time=0.228 ms

That looks good! Let's continue.

Pod to Service Communication Dual-stack

For the pod-to-service connectivity test, we will create a new Deployment using the inanimate/echo-server image. We will then expose the Deployment to a ClusterIP service on port 8080 and define the ipFamilyPolicy and ipFamilies service specifications based on the dual-stack example.

• The example can be found here.

$ kubectl create deploy echo-server --image=inanimate/echo-server

$ kubectl expose deploy echo-server --port=8080

$ kubectl get pods,svc
NAME                               READY   STATUS    RESTARTS   AGE
pod/echo-server-55c585ccd7-dd65x   1/1     Running   0          20s
pod/test01                         1/1     Running   0          8m2s
pod/test02                         1/1     Running   0          8m2s

NAME                  TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)    AGE
service/echo-server   ClusterIP   10.43.108.176   <none>        8080/TCP   5s
service/kubernetes    ClusterIP   10.43.0.1       <none>        443/TCP    21m

Let's edit the service echo-server define the ipFamilyPolicy as PreferDualStack, include IPv6 to the ipFamilies and continue with the remaining tests.

$ kubectl edit svc echo-server
apiVersion: v1
kind: Service
metadata:
  labels:
    app: echo-server
  name: echo-server
  namespace: default
spec:
  clusterIP: 10.43.108.176
  clusterIPs:
  - 10.43.108.176
  internalTrafficPolicy: Cluster
  ipFamilies:
  - IPv4
  - IPv6
  ipFamilyPolicy: PreferDualStack
  ports:
  - port: 8080
    protocol: TCP
    targetPort: 8080
  selector:
    app: echo-server
  sessionAffinity: None
  type: ClusterIP

$ kubectl describe svc echo-server
Name:              echo-server
Namespace:         default
Labels:            app=echo-server
Annotations:       <none>
Selector:          app=echo-server
Type:              ClusterIP
IP Family Policy:  PreferDualStack
IP Families:       IPv4,IPv6
IP:                10.43.108.176
IPs:               10.43.108.176,2001:face:43::9f4c
Port:              <unset>  8080/TCP
TargetPort:        8080/TCP
Endpoints:         10.42.1.107:8080
Session Affinity:  None
Events:            <none>

Connectivity Tests

$ kubectl exec -it test01 -- curl http://echo-server.default:8080
Welcome to echo-server!  Here's what I know.
  > Head to /ws for interactive websocket echo!

-> My hostname is: echo-server-55c585ccd7-dd65x

-> Requesting IP: [2001:face:42::c36e]:39452

-> Request Headers |

  HTTP/1.1 GET /

  Host: echo-server.default:8080
  Accept: */*
  User-Agent: curl/8.7.1

$ kubectl exec -it test01 -- curl http://10.43.108.176:8080
Welcome to echo-server!  Here's what I know.
  > Head to /ws for interactive websocket echo!

-> My hostname is: echo-server-55c585ccd7-dd65x

-> Requesting IP: 10.42.0.94:39162

-> Request Headers |

  HTTP/1.1 GET /

  Host: 10.43.108.176:8080
  Accept: */*
  User-Agent: curl/8.7.1

$ kubectl exec -it test01 -- curl http://[2001:face:43::9f4c]:8080
Welcome to echo-server!  Here's what I know.
  > Head to /ws for interactive websocket echo!

-> My hostname is: echo-server-55c585ccd7-dd65x

-> Requesting IP: [2001:face:42::c36e]:47332

-> Request Headers |

  HTTP/1.1 GET /

  Host: [2001:face:43::9f4c]:8080
  Accept: */*
  User-Agent: curl/8.7.1

From the outputs it is visible the echo-server service can talk IPv4 and IPv6.

Second RKE2 Cluster

Repeat the steps above for the second cluster. Ensure the cluster-cidr and the service-cidr are not overlapping. You can use the below as an example.

cluster-cidr: "10.44.0.0/16,2001:cafe:42::/56"
service-cidr: "10.45.0.0/16,2001:cafe:43::/112"

Resources

• Dual Stack on AKS by Amit Gupta
• eCHO Episode 59: Dual Stack with Cilium

Next Steps

In the upcoming post, we will set up a Cilium Service Mesh and share IPv4 and IPv6 Global Services.

✉️ Contact

If you have any questions, feel free to get in touch! You can use the Discussions option found here or reach out to me on any of the social media platforms provided. 😊 We look forward to hearing from you!

Conclusions

Dual-stack deployment on an RKE2 cluster, check! ✅ Thanks for reading, and stay tuned for the upcoming posts!
