Mkdocs: Documentation Versioning with Mike
Summary:
Learn how to implement documentation versioning in MkDocs using Mike. Mike is a plugin designed for managing multiple documentation versions. The guide covers setting up versioning from day one and integrating it with GitHub Pages for streamlined, automated deployments.
Introduction
MkDocs is an easy and super fast way to create static sites using .md files while Mike is a plugin used to enable documentation versioning.
What is document version control? It is a feature that records changes to a document or a set of documents over time. It lets you keep track of the most recent document while preserving earlier versions.
Why document version control is important? There are multiple reasons why keeping track of a document is important. Prevents data loss through easy restoration of previous versions, and ensures consistency and accuracy by tracking changes and maintaining a single updated document. Helps end-users guide through the documentation based on a particular version.
Scenario
The scenario in my case was the need to keep track of documentation changes and software releases. As the software releases became more frequent, multiple documentation changes had to happen. Thus, keeping a clean state of the dev and the latest release version was crucial. Having said that, locating descriptive documentation on how to integrate MkDocs with Mike was not easy. The MkDocs official documentation provided initial details, but not enough to perform the required changes to include versioning.
Because I was not able to test changes in real-time I decided to create a new repository for the MkDocs site and integrate Mike as the versioning plugin. The approach, commands and configuration details performed are listed in the below sections.
GitHub Resources
The showcase repository is available here.
MkDocs Initial Documentation
Create and Activate a Python Virtual Environment
To work with MkDocs, we need Python 3.x installed locally. Python is used to instantiate a virtual environment and install the required packages for MkDocs.
$ python3 --version # Use the command to ensure Python3.x is installed locally
$ python3 -m venv ./venv # Use the Python virtual environment module
$ source ./venv/bin/activate # Activate the virtual environment
Install MkDocs
$ pip3 install mkdocs-material # Install mkdocs-material
We installed the mkdocs-material package instead of mkdocs as the first one can be easily extended and provides many options to alter the appearance and behaviour of the site.
Create a New Project
Once MkDocs is installed in the Python virtual environment, we can execute mkdocs commands and proceed with our goal of creating a nice documentation with versioning.
$ mkdocs create example-project # Create a MkDocs project with the name example-project
The above command will create the project for us and include all the required components to build and locally serve the documentation. The folder outline is listed below.
.
├── docs
│ └── index.md
├── LICENSE
├── mkdocs.yml
└── README.md
Build and Serve the Documentation
$ mkdocs build # The command builds a static site. A new folder named site is included in the existing directory
To see how the documentation looks like in a browser, we need to serve the site. To do that, execute the below command.
$ mkdocs serve
If no error occurs while building and/or serving the site, the documentation will be accessible on http://127.0.0.1:8000/.
Install and Configure Mike
To proceed further, we will install Mike in the Python virtual environment and then perform small updates to the mkdocs.yml file.
Install Mike
$ pip3 install mike
$ mike --version
Update mkdocs.yml
Based on Mike official documentation, we will enable the plugin and include extra variables for aliases and default versioning names in the mkdocs.yml file. See the configuration below.
extra:
version:
provider: mike
alias: true
default:
- latest
plugins:
- mike
Optionally, you can specify the site_name and repo_name in the same file. Similar the code below.
site_name: Mkdocs Versioning Example
site_url: https://egrosdou01.github.io/mkdocs-versioning-example/
repo_name: egrosdou01/mkdocs-versioning-example
repo_url: https://github.com/egrosdou01/mkdocs-versioning-example
Setup GitHub Workflows
As we want to automate the build and deployment of the documentation, we will create two GitHub workflows for a dev version and a prod version.
Dev Workflow
name: CI Build Dev Docu
on:
push:
branches:
- main
permissions:
contents: write
jobs:
deploy:
runs-on: ubuntu-latest
steps:
- uses: actions/checkout@v4
with:
fetch-depth: 0
- uses: actions/setup-python@v5
with:
python-version: 3.x
- name: Install Dependencies
run: |
pip install mkdocs-material
pip install mike
- name: Setup Docs Deploy
run: |
git config --global user.name "Example Docu Deploy"
git config --global user.email "docs.deploy@eleni.dev"
- name: Build Docs Site
run: |
mike deploy --push --update-aliases dev
mike set-default dev --push
Prod Workflow
name: CI Build Prod Docu
on:
release:
types: [published]
permissions:
contents: write
jobs:
deploy:
runs-on: ubuntu-latest
steps:
- uses: actions/checkout@v4
with:
fetch-depth: 0
- uses: actions/setup-python@v5
with:
python-version: 3.x
- name: Install Dependencies
run: |
pip install mkdocs-material
pip install mike
- name: Setup Docs Deploy
run: |
git config --global user.name "Example Docu Deploy"
git config --global user.email "docs.deploy@eleni.dev"
- name: Build Docs Site
run: mike deploy --push --update-aliases ${{ github.event.release.tag_name }} latest
Looking at both GitHub workflows, the dev workflow is created based on a push action to the main branch while the prod documentation is created only when a new Release is created in the defined repository. The prod documentation will be marked as the latest version.
Initial Push
It is time to push our code to GitHub. Ensure the venv folder is excluded from the push with the use of the .gitignore file. Once we ensure everything is up to date, perform the below to push directly to the main branch.
$ git add .
$ git commit -m "Initial commit"
$ git push origin main
If you do not have a repository already, feel free to follow the getting started guide from GitHub located here. For GitHub Pages to be functional a public repository needs to be created.
Once the code is pushed, we will see the dev GitHub workflow has already been triggered. Check out the Repository Name > Actions section.
How does Mike keep track of versions?
The Mike plugin under the hood leverages the Git branches to manage the history of the documentation site. Every version that gets deployed with Mike, is committed to the gh-pages branch and into a separate directory. Apart from that, in the gh-pages branch, the versions.json file is stored and effectively is the source of truth of all existing versions alongside defined aliases.
Enable GitHub Pages
Once the dev GitHub workflow is finished successfully, a new branch named gh-pages will be available. This is where our site is built and stored. To make the site available to the world, we have to enable the GitHub pages. Effectively, navigate to Settings > Code and Automation -> Pages > Build and Deployment -> Branch > Choose the gh-pages > Save. For more information about the GitHub pages, have a look here.
Once you click save for the page configuration, a new Github action will get triggered and will build the site for you. The site will be available at a similar link https://<GitHub username>.github.io/<Repository Name>/.
Create Release Tag
To include the latest release within our documentation, we can create a new branch, perform and push changes and then create a new Release with an associated tag. For more information about Releases and Tags, have a look here. Once this is performed, the prod GitHub workflow will get triggered and upon successful execution, the gh-pages action will be initiated.
Conclusion
If you want to take your team’s or project’s documentation to the next level, using MkDocs together with Mike offers a clean, structured, and professional way to manage and version your docs! Happy coding!
