Talos, Proxmox and OpenTofu: Beginner's Guide – Part 1

November 24, 2024 · 10 min read

DevOps Consulting Engineer at Cisco Systems

Introduction

It's been a while now since I am bootstrapping RKE2 and K3s clusters on different platforms, on-prem and in the cloud, including VMware, Proxmox, Nutanix and pretty much every well-known cloud provider. This week, I have decided to take a different approach and discover something new! Bootstrap a Talos Kubernetes cluster on Proxmox using OpenTofu as the Infrastructure as Code (IaC) solution. My first interaction with Talos Linux was a couple of months back when Justin Garrison posted something about the ease of Kubernetes cluster deployment. I did not have much time back then, but here we come!

The blog post will be split into two parts. Part 1 will include a basic deployment of a Talos cluster using the out-of-box configuration, while Part 2 will contain the required configuration changes to use Cilium as our CNI. Get ready to roll up your sleeves and dive into the essentials of Talos Linux with OpenTofu on Proxmox.

title image reading "Talos Cluster on Proxmox with OpenTofu"

Lab Setup

+------------------------------+-----------+
|         Deployment           |  Version  |
+------------------------------+-----------+
|        Proxmox VE            |    8.2.4  |
|   Talos Kubernetes Cluster   |    1.8.1  |
+------------------------------+-----------+
+-----------------------------+-----------+
|       OpenTofu Providers    |  Version  |
+-----------------------------+-----------+
|      opentofu/random        |    3.6.2  |
|      telmate/proxmox        | 3.0.1-rc4 |
|      siderolabs/talos       |    0.6.1  |
+-----------------------------+-----------+
+------------------------+---------------------+
|        Binaries        |        Version      |
+------------------------+---------------------+
|         tofu           |    OpenTofu v1.8.1  |
|        kubectl         |        v1.30.2      |
+------------------------+---------------------+

GitHub Resources

The showcase repository is available here.

Prerequisites

Manual Bootstrap (Optional)

If you are new to the concept of bootstrapping Kubernetes clusters, it might be worth familiarising yourself with Talos and trying to bootstrap a cluster using talosctl and Docker. Check out the link here.

Proxmox API Token

To authenticate with Proxmox while executing the tofu plan, we need an API token with the right permissions.

From the Proxmox UI, navigate to Datacenter > Permissions
Click on Roles and create a role with the appropiate permissions to allow the creation of VMs alognside other activities. More information can be found here.
Click on Users and create a user that will be used for the execution of the tofu plan
Click on Permissions and associate the user with the role
Click on API Tokens and create a new API Token. Specify the authenticaiton method, the user, the token ID alongside unselecting the Privilege Separation button

More about API tokens and Access Control Lists (ACLs), check out the link.

Retrieve and Upload Custom ISO

As the Talos Linux image is immutable, we will download a factory image from the link and include the QEMU Guest Agent to allow reporting of the virtual machine status to Proxmox.

Steps taken

Access the URL
Set Hardware Type: Bare-metal Machine
Set Talos Linux Version: 1.8.1
Set Machine Architecture: amd64 (for my environment)
Set System Extensions: siderolabs/qemu-guest-agent (9.1.0)
Set Customization: Nothing to choose there
Last Overview Page: Copy the First Boot .iso link and the Initial Installation link

Upload the .iso to the Proxmox server. Make a copy of the Initial Installation link.

Scenario Overview

In today's post, we will perform the below using the IaC approach. As this is a beginner guide, we will keep the code as simple as possible including relevant comments and notes. For the setup, we will use DHCP to hand over IPs to the endpoints.

The deployment in a Nutshell 👇

Create virtual machines using the Talos Linux image
Specify the endpoint for the Kubernetes API
Generate the machine configurations (part 1 uses the default ones)
Apply the machine configurations to the virtual machines
Bootstrap a Kubernetes cluster

Talos Linux - Why bother?

Going through the official documentation here, I stumbled upon the fact that Talos Linux is a secure, immutable, and minimal OS designed for Kubernetes, with system management via API, production-ready support for cloud, bare metal, and virtualization platforms. Cool, right?

File structure

files/: Contains files and templates for the initial image configuration of the Talos cluster
providers.tf: Contains the required providers used in the resource blocks
virtual_machines.tf: Contains the resources to spin up the virtual machines
main.tf: Contains the resource blocks for the Talos Linux bootstrap
data.tf: Contains several data required for the Talos cluster bootstrap proccess
variables.tf: Contains the variable declaration used in the resource blocks
output.tf: Contains the output upon successful completion of the OpenTofu plan/apply
*.tfvars: Contains the default values of the defined variables

OpenTofu Provides

As with any Terraform/OpenTofu setup, we have to define the providers and versions we would like to use. If you are not aware of the term Provider, have a look here.

The telmate/proxmox provider details and the how to guide, are located here
The siderolabs/talos provider details and the how to guide, are located here

terraform {
  required_version = "~> 1.8.1"
  required_providers {
    random = {
      source  = "opentofu/random"
      version = "3.6.2"
    }
    proxmox = {
      source  = "registry.opentofu.org/telmate/proxmox"
      version = "3.0.1-rc4"
    }
    talos = {
      source  = "registry.opentofu.org/siderolabs/talos"
      version = "0.6.1"
    }
  }
}
provider "proxmox" {
  pm_api_url          = file(var.api_url)
  pm_api_token_id     = file(var.api_token_id)
  pm_api_token_secret = file(var.api_token_secret)
  pm_tls_insecure     = true
}

At this point, we defined the preferred provider versions and the way to authenticate with the Proxmox server. For this demonstration, I am using .txt files in a directory to store sensitive data and exclude them with the .gitignore.

Virtual Machines Setup

As we have two types of machines, controller and worker node, I have decided to keep the configuration as simple as possible and avoid using one node for both types. That means, we will have two resources to create the controller and the worker nodes.

# Create the controller and worker Nodes
resource "proxmox_vm_qemu" "talos_vm_controller" {
  for_each = var.controller
  name        = "${each.value.name}-${random_id.cluster_random_name.hex}"
  target_node = var.vm_details.target_node
  vmid        = each.value.vmid

  # Basic VM settings here. agent refers to guest agent
  agent   = var.vm_details.agent_number
  cores   = each.value.vcores
  sockets = var.vm_details.socket_number
  cpu     = var.vm_details.cpu_type
  memory  = each.value.vram
  scsihw  = var.vm_details.scsihw
  qemu_os = var.vm_details.qemu_os
  onboot  = var.vm_details.onboot
  disks {
    ide {
      ide0 {
        cdrom {
          iso = var.vm_details.iso_name
        }
      }
    }
    scsi {
      scsi0 {
        disk {
          size    = each.value.hdd_capacity
          storage = var.vm_details.storage
        }
      }
    }
  }
  network {
    model  = each.value.vmodel
    bridge = each.value.vnetwork
  }
  lifecycle {
    ignore_changes = [
      network, disk, target_node
    ]
  }
  ipconfig0  = var.vm_details.ipconfig
  nameserver = var.vm_details.nameserver
}

note

From the above, it is important to set the agent to 1 to enable the QEMU quest agent. We populate the first part of the disk config with the .iso name uploaded to Proxmox in an earlier state.

Bootstrap Talos Kubernetes Cluster

Following the example located here, the below data and resources defined. The first step is to boot a virtual machine using the factory image and then use the initial image after the first reboot. The initial image details are provided during the talos_machine_configuration for the controller and the worker node.

data.tf

# Define the Initial Image link copied from the Talos Factory guide from an earlier stage
locals {
  initial_image = "factory.talos.dev/installer/${var.talos_cluster_details.schematic_id}:${var.talos_cluster_details.version}"
}
# Generate the Talos client configuration
data "talos_client_configuration" "talosconfig" {
  cluster_name         = var.talos_cluster_details.name
  client_configuration = talos_machine_secrets.this.client_configuration
  endpoints            = [for v in proxmox_vm_qemu.talos_vm_controller : v.default_ipv4_address]
  nodes                = [for v in proxmox_vm_qemu.talos_vm_controller : v.default_ipv4_address]
}
# Generate the controller configuration and instantiate the Initial Image for the Talos configuration
data "talos_machine_configuration" "machineconfig_controller" {
  cluster_name     = var.talos_cluster_details.name
  talos_version    = var.talos_cluster_details.version
  cluster_endpoint = "https://${tolist([for v in proxmox_vm_qemu.talos_vm_controller : v.default_ipv4_address])[0]}:6443" # Use the first controller node IP address from the list as the cluster_endpoint
  machine_type     = "controlplane"
  machine_secrets  = talos_machine_secrets.this.machine_secrets
  config_patches = [
    templatefile("${path.module}/files/init_install.tfmpl", {
      initial_image = local.initial_image
  })]
}
# Generate the worker configuration and instantiate the Initial Image for the Talos configuration
data "talos_machine_configuration" "machineconfig_worker" {
  cluster_name     = var.talos_cluster_details.name
  talos_version    = var.talos_cluster_details.version
  cluster_endpoint = "https://${tolist([for v in proxmox_vm_qemu.talos_vm_controller : v.default_ipv4_address])[0]}:6443" # Use the first controller node IP address from the list as the cluster_endpoint
  machine_type     = "worker"
  machine_secrets  = talos_machine_secrets.this.machine_secrets
  config_patches = [
    templatefile("${path.module}/files/init_install.tfmpl", {
      initial_image = local.initial_image
  })]
}

main.tf

# Generate machine secrets for Talos cluster
resource "talos_machine_secrets" "this" {
  talos_version    = var.talos_cluster_details.version
}
# Apply the machine configuration created in the data section for the controller node
resource "talos_machine_configuration_apply" "controller_config_apply" {
  for_each                    = { for i, v in proxmox_vm_qemu.talos_vm_controller : i => v }
  depends_on                  = [proxmox_vm_qemu.talos_vm_controller]
  client_configuration        = talos_machine_secrets.this.client_configuration
  machine_configuration_input = data.talos_machine_configuration.machineconfig_controller.machine_configuration
  node                        = each.value.default_ipv4_address
}
# Apply the machine configuration created in the data section for the worker node
resource "talos_machine_configuration_apply" "worker_config_apply" {
  for_each                    = { for i, v in proxmox_vm_qemu.talos_vm_worker : i => v }
  depends_on                  = [proxmox_vm_qemu.talos_vm_worker]
  client_configuration        = talos_machine_secrets.this.client_configuration
  machine_configuration_input = data.talos_machine_configuration.machineconfig_worker.machine_configuration
  node                        = each.value.default_ipv4_address
}
# Start the bootstrap of the cluster
resource "talos_machine_bootstrap" "bootstrap" {
  depends_on           = [talos_machine_configuration_apply.controller_config_apply]
  client_configuration = talos_machine_secrets.this.client_configuration
  node                 = tolist([for v in proxmox_vm_qemu.talos_vm_controller : v.default_ipv4_address])[0]
}
# Collect the kubeconfig of the Talos cluster created
resource "talos_cluster_kubeconfig" "kubeconfig" {
  depends_on           = [talos_machine_bootstrap.bootstrap, data.talos_cluster_health.cluster_health]
  client_configuration = talos_machine_secrets.this.client_configuration
  node                 = tolist([for v in proxmox_vm_qemu.talos_vm_controller : v.default_ipv4_address])[0]
}
...

Tofu Execution Plan

$ tofu init
$ tofu plan
$ tofu apply

Plan Output

Within less than 5 minutes, we have a fully functional Kubernetes cluster (assuming the cluster is in healthy state). To interact with it, we need the kubeconfig. This is retrieved from the talos_cluster_kubeconfig data source defined in the data.tf file. The complete data.tf file is located here.

output "kubeconfig" {
  value     = resource.talos_cluster_kubeconfig.kubeconfig.kubeconfig_raw
  sensitive = true
}

note

I had to set a sleep condition between the bootstrap and the health check condition. The health state was always failing for my setup even if a timeout was defined within the data definition.

tip

If you want to use the talosctl to check the status of the cluster, the service running etc., feel free to collect the talos_config from the client configuration.

output "talos_configuration" {
  value     = data.talos_client_configuration.talosconfig.talos_config
  sensitive = true
}

Retrieve kubeconfig

$ tofu output kubeconfig
$ export KUBECONFIG=<Directory of the kubeconfig>
$ kubectl get nodes -o wide
NAME            STATUS   ROLES           AGE     VERSION   INTERNAL-IP    EXTERNAL-IP   OS-IMAGE         KERNEL-VERSION   CONTAINER-RUNTIME
talos-04v-eny   Ready    control-plane   3m45s   v1.31.1   x.x.x.x        <none>        Talos (v1.8.1)   6.6.54-talos     containerd://2.0.0-rc.5
talos-af3-vad   Ready    control-plane   3m45s   v1.31.1   x.x.x.x        <none>        Talos (v1.8.1)   6.6.54-talos     containerd://2.0.0-rc.5
talos-hi4-p4z   Ready    <none>          3m52s   v1.31.1   x.x.x.x        <none>        Talos (v1.8.1)   6.6.54-talos     containerd://2.0.0-rc.5
talos-yvq-7ic   Ready    <none>          3m39s   v1.31.1   x.x.x.x        <none>        Talos (v1.8.1)   6.6.54-talos     containerd://2.0.0-rc.5

Resources

Part-2 Outline

In Part 2, we will cover how to update the default CNI with Cilium. Stay Tuned!

✉️ Contact

If you have any questions, feel free to get in touch! You can use the Discussions option found here or reach out to me on any of the social media platforms provided. 😊 We look forward to hearing from you!

Conclusions

Hope the post gave you an overview on how to bootstrap a basic Talos Linux cluster with OpenTofu! The Siderolab folks prepared material for beginners and experts on how to deploy Talos Linux clusters!
