Better Together: Sveltos to Automate Flux Helm Releases
Summary:
In part 1 of the series, we explored how Sveltos acts as the main brain for our deployments to a fleet of clusters. However, this is the case when we start with Continuous Deployments (CD) or when we are willing to perform a full migration to a new architecture. The next two posts are dedicated to the collaboration between Flux and Sveltos. Flux remains the core way of deploying applications using the Flux Customer Resource Definitions (CRDs), while Sveltos enters the play when we talk about scalability, automation, and dynamic instantiation of deployments.
Motivation
Most engineers working in Platform Engineering already have a GitOps Controller like ArgoCD or Flux in place for Kubernetes deployments. It works, and it works well, until it does not. As teams grow and deployments spread across ten or more clusters, multiple environments, and different Hyperscalers, a once clean GitOps repository quickly ends up with duplicated Helm Releases, environment-specific overrides, and manual interventions nobody wants to own.
Having only a GitOps Controller in place is not enough when it comes to complex workloads, scalability, and management of deployments and add-ons across different environments. Teams end up juggling multiple tools just to add flexibility to an existing setup. Can we help teams work smaller, simpler, and not harder when it comes to continuous deployments? The answer is yes; follow along to explore the Sveltos magic! 🪄
Scenario
In today's post, we will showcase a flexible way of using an existing Flux configuration, and how by adding Sveltos into the mix, we provide out-of-the-box capabilities like templating, event-driven workloads, and many more. We will work with an existing Flux deployment, and Sveltos will automate the dynamic creation of Flux Helm Releases based on a cluster type or identity.
Lab Setup
+-------------------------------+---------------------+
| Deployment | Version |
+-------------------------------+---------------------+
| RKE2 | v1.35.3+rke2r3 |
| Sveltos | v1.8.0 |
| Flux2 Helm | v2.18.3 |
| Flux Operator Helm | v0.40.0 |
+-------------------------------+---------------------+
GitHub Resources
The YAML outputs are not complete. Have a look at the GitHub repository.
Prerequisites
- A Kubernetes cluster acting as the management cluster
- At least one managed cluster
- Familiarity with Kubernetes manifest files
- Familiarity with Flux
Diagram
The diagram looks very similar to the one we saw in part 1 of the series. The difference here is that we already have a Flux deployment and project outline. We will install Sveltos using the native deployment options and let Sveltos listen for Events or specific resources and automate the deployment of Flux Helm Releases. Let's dive into the details.
Sveltos Installation
The installation of Sveltos using Flux could be similar to the below. Feel free to use your preferred way of installing Sveltos to the management cluster.
---
apiVersion: v1
kind: Namespace
metadata:
name: projectsveltos
---
apiVersion: source.toolkit.fluxcd.io/v1
kind: HelmRepository
metadata:
name: projectsveltos
namespace: flux-system
spec:
interval: 24h
url: https://projectsveltos.github.io/helm-charts
---
apiVersion: helm.toolkit.fluxcd.io/v2
kind: HelmRelease
metadata:
name: projectsveltos
namespace: flux-system
spec:
interval: 30m
targetNamespace: projectsveltos
storageNamespace: projectsveltos
chart:
spec:
chart: projectsveltos
version: ">=1.6.1"
sourceRef:
kind: HelmRepository
name: projectsveltos
namespace: flux-system
interval: 12h
install:
crds: Create
createNamespace: true
timeout: 10m
strategy:
name: RetryOnFailure
upgrade:
crds: CreateReplace
timeout: 10m
cleanupOnFail: true
strategy:
name: RetryOnFailure
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
resources:
- sveltos-helmrelease.yaml
The above yaml definition will install Sveltos to the management cluster in the projectsveltos nasmespace. The namespace is not negotiable. Sveltos has to be installed in this namespace.
Label Management Cluster
To control resources in the management cluster with Sveltos, we will simply add the label type: mgmt to the sveltoscluster named mgmt in the mgmt namespace. The registration is done by Sveltos during installation. No manual intervention is needed. When we refer to the management cluster, is the cluster where Flux and Sveltos are installed.
$ kubectl label sveltoscluster mgmt -n mgmt type=mgmt
Automate Flux Helm Releases
How does it work?
Sveltos works very well with the concept of labeling. We can label clusters with a dedicated key: value pair and use this information to dynamically create Flux Helm Releases based on our needs. In this example, everytime a cluster with the label cert-manager: required appears, we trigger an action and dynamically pre-instantiate and deploy a Flux Helm Release using the information located in the management cluster. To achieve our goal, we use the Sveltos Event Framework.
Define an EventSource
A Sveltos EventSource is a simple way of instructing Sveltos to look for an event or a specific resource. This can be an Event within a cluster or an Event outside a cluster like NATs. In our case, we want to detect clusters with the label set to cert-manager: required.
apiVersion: lib.projectsveltos.io/v1beta1
kind: EventSource
metadata:
name: detect-cluster-requiring-cert-manager
spec:
collectResources: true
resourceSelectors:
- group: "lib.projectsveltos.io"
version: "v1beta1"
kind: "SveltosCluster"
labelFilters:
- key: cert-manager
operation: Equal
value: required
Define an EventTrigger
Once an EventSource is detected, an action or multiple actions can be triggered. In this example, once an event is detected, we will deploy a ConfigMap to the management cluster which includes the Flux Helm Releases details expressed as a Sveltos template.
apiVersion: lib.projectsveltos.io/v1beta1
kind: EventTrigger
metadata:
name: deploy-cert-manager
spec:
sourceClusterSelector:
matchLabels:
type: mgmt
destinationClusterSelector:
matchLabels:
type: mgmt
eventSourceName: detect-cluster-requiring-cert-manager
oneForEvent: true
policyRefs:
- name: cert-manager-helmrelease
namespace: default
kind: ConfigMap
Automate Flux Helm Releases
Now that we have our EventSource and EventTrigger in place, we need to define what actually gets deployed when an event is detected. We do this using a ConfigMap that holds the Flux Helm Release definition expressed as a Sveltos template.
apiVersion: v1
kind: ConfigMap
metadata:
name: cert-manager-helmrelease
namespace: default
annotations:
projectsveltos.io/instantiate: ok
data:
cert-manager.yaml: |
apiVersion: helm.toolkit.fluxcd.io/v2
kind: HelmRelease
metadata:
name: cert-manager-{{ .Resource.metadata.name }}
namespace: {{ .Resource.metadata.namespace }}
spec:
interval: 15m
kubeConfig:
secretRef:
name: {{ .Resource.metadata.name }}-sveltos-kubeconfig
key: kubeconfig
chart:
spec:
chart: cert-manager
version: "v1.16.x"
sourceRef:
kind: HelmRepository
name: jetstack
namespace: flux-system
interval: 15m
install:
createNamespace: true
timeout: 10m
remediation:
retries: 3
upgrade:
timeout: 10m
cleanupOnFail: true
remediation:
retries: 3
strategy: rollback
values:
crds:
enabled: true
keep: true
The annotation projectsveltos.io/instantiate: ok is what converts a plain ConfigMap into a Sveltos template. Sveltos will pull information directly from the management cluster and dynamically pre-instantiate and deploy the resource using the detected cluster's metadata. Notice how {{ .Resource.metadata.name }} and {{ .Resource.metadata.namespace }} are automatically resolved per cluster, one template, many clusters. The ConfigMap can be further templatised based on different use cases. Both Lua and CEL languages are supported for Sveltos templating.
The label-based approach covered here applies to any application. Explore the patterns that fit your use case and adapt them to your needs.
Result
Every time a cluster with the label cert-manager: required appears, Sveltos detects the event, resolves the template, and dynamically creates a dedicated Flux Helm Release using that cluster's information. No manual intervention, no duplicated YAML. One template, one label, done.
Conclusion
In this post, we explored how Sveltos and Flux can work together without replacing one another. Flux remains the backbone of your GitOps workflow, while Sveltos adds the intelligence layer on top, handling scalability, dynamic templating, and event-driven automation with minimal overhead. By combining the EventSource, EventTrigger, and a templated ConfigMap, we reduced what would otherwise be repetitive, manually maintained Flux Helm Release definitions into a single, reusable template. The moment a cluster is labeled cert-manager: required, Sveltos takes over and does the heavy lifting automatically.
The key takeaway: you do not need to abandon your existing Flux setup to benefit from Sveltos. You layer it in, and your platform becomes smarter, not more complex.
What's Next?
In the next post, we will work with a simple hub-spoke Flux deployment as our basis, and include Sveltos installation alongside the Event Framework approach to automate Flux Helm Releases. Stay tuned!
